3U rack; shield for 5-port switch
This is a shield for a 5-port switch from TP-Link. It is part of a project in which I mounted 3 Raspberry Pi's and a USB hard-drive in a 3U Europac case. Since there are no screw holes in the switch I needed to come up with something with a automatic locking mechanism using the wall mounting holes of the switch.Not every switch is a 5-port and an available case may be different as well. Therefor I added the SCAD file, so everyone can change whatever is needed.The project was inspired by the great design from Kapozok (https://www.thingiverse.com/thing:1793758) and SliderBOR https://www.thingiverse.com/thing:3022136. The other shields (RasPI and HD) will be available soon, also in SCAD format.
