Washer

Customized version of http://www.thingiverse.com/thing:193647
Created with Customizer! http://www.thingiverse.com/apps/customizer/run?thing_id=193647
Instructions
Using the following options:
wing_ratio = 1
slot_width = 1
thread_step = 2
thread_length = 25
nut_type = normal
non_thread_length = 0
nut_height = 6
drive_diameter = 5
drive_type = socket
step_shape_degrees = 45
socket_depth = 3.5
texture = exclude
thread_outer_diameter = 8
socket_facets = 6
nut_thread_outer_diameter = 9
nut_diameter = 12
nut_step_shape_degrees = 45
outer_diameter = 7
head_type = hex
slot_depth = 2
head_diameter = 12
resolution = 0.5
nut_thread_step = 2
thickness = 10.5
non_thread_diameter = 0
head_height = 5
countersink = 2
facets = 6
type = washer
inner_diameter = 3.5


Category: Parts
