Tinyboy remix

SummaryTinyboy remix:
OLED case
footer for extruder mount
Tinyboy BOM:
Lasercut Acrylic x 1
bearing 603zz x 6
604uu (for extruder) x 1
bearing LM4UU x 12
Phillips Head M2.5 5mm x 10
Phillips Head M2 8mm x 6
Phillips Head M3 5mm x 16
Hex Screw M3 10mm x 15
Hex Screw M3 12mm x 17
Hex Screw M3 16mm x 5
Hex Screw M3 22mm x 4
Hex Screw M4 10mm x 2
Hex Screw M4 8mm x 4
Screw shaft M3 180mm x 1
M3 nut x 17
M3 brass stud 6mm x 6
M3 washer 70.5 x 16
M3 washer 90.8( for belt bearing) x 6
M4 washer x 2
Rod 4mm 130mm x 2
Rod 4mm 140mm x 2
Rod 4mm180mm x 2
fastener 2.5mm x 22
stepper_28 x 3
stepper_42(For Extruder) x 1
pulley MXL 16T x 2
Coupling 3mm x 3mm x 1
Timing Belts MXL - 4mm x 1M (Y Axis 43cm, X Axis 47cm)
mega2560 ramps1.4 with 4 A4988 stepstick x 1
Micro switch (for endstop) x 3
Extruder (mk8) x 1
e3dv6 x 1
PTFE OD 4mm ID 2mm L 60cm x 1
12V 6A Transformer x 1
Control box - m3 x 12mm x3
-- back cover x1
-- stand x2 InstructionsOLED support only fixed with adhesive tape
Control box - m3 x 12mm x3
-- back cover x1
-- stand x2
