Stationary Dice

prusaprinters

See it in action: Features:Easily prints in multiple colorsCan use multiple dice-face colors per “die”Use PrusaSlicer negative volume feature to create any style of dice facesAssembles without glueRotates nicely without bearings, though common 608 bearings can be used.Uses common magnets to enable discreet stopping pointsAll magnets pop out with a paper clipDice can be grouped in any number of configurationsEasily take dice off of assembly to use in different configurationsPrints without supportsPrints at 0.3mm layer height on a 4mm nozzleMagnets needed:Each “die” uses 6  magnets that are 3mm in diameter with a height of 1.6 mm, though the height can be lessEach support uses one 3/16-inch-diameter by 1/16-inch-height magnet for attraction to the neighboring “die”. A second 3mm x 1.6mm magnet can be used to repel the neighboring “die”. The repelling magnet reduces (though does not eliminate) the possibility of the die stopping halfway between the attracting magnets.Instructions:No supports needed for any models.I print at 0.3mm layer height except for the nut and bolt. I print those at 0.2mm.All pieces can snap together. No glue needed. A small hammer may be needed to fully seat the magnetsMagnets can be popped out with a paper clip inserted from the other side.Some rubber feet on the bottom of the base help prevent slipping on smooth surfaces.Face the supports so that the magnets on the support do not touch the magnets on the dice. (See photos)
