SOCKET HOLDER

This frame is very useful to fix an outdoor power socket to a 60 mm diameter circular pole.
To mount it, two Serflex type clamps will be used.
This holder can also be used for many other fixings.
The tool is particularly suited to supporting a sealed electrical outlet outside the home.
The distance between the four holes of this bracket fit that of the VIMAR outdoor watertight socket mod. 14962, but it is possible to make other holes (with a drill) to fix different models or different tools.
This bracket was printed in PETG (although printing in PLA is possible, but I advise against it as it would be quite weak) with a layer thickness of 0.30mm and a 100% linear infill.
The attached .STL file also allows you to fix layer thicknesses of 0.20 mm which, in addition to a better aesthetic result, also gives greater mechanical resistance, but with longer printing times.
The attached .GCODE file is already ready for printing, it is suitable for an Ender 3 PRO printer and is set for 0.30 mm layers. To reduce the effects of shrinkage at the base of the model, two flanges are positioned that hook better to the print bed.
It was printed with an Ender 3 PRO printer on a crystal bed treated with a light spray of hairspray just before printing.
