RC SkidSteer V3.0 Printability Upgrades

prusaprinters

All parts are 100% compatible with original model. All parts are printable with 0.2mm layer height. 1_main_housingRemoved the bottom fillet with extreme overhangs and replaced it with a less steep chamfer.Reduced back of the arm motor mount by -0.18 mm to prevent overlap with the back cover.Added fillets and chamfers for a nicer result.4_left_armReduced the diameter of the depression in the arm mount for shorter bridges.Split bridges around inner holes to allow printing without supports.5_right_armReduced the diameter of the depression in the arm mount for shorter bridges.Split bridges around inner holes to allow printing without supports.6_hubSplit bridges around inner holes to enable printing without supports.12_drivers_cageRemoved unprintable overhangs at the front and added necessary chamfers.Removed unprintable overhangs from the bottom line (top when printed) of the grid pattern (which was slightly angled).Added a chamfer at the top to create less sharp edges. These are not printability improvements, but feel free to use them:Optional - 14_motor_coverAdded gearbox cover to the motor restraint .Optional - 25_track_tensioner_rollerRemoved depression for screwdriver, if you don't want it. You will probably need to screw wheel base before snapping the wheel in place.
