PopSocket Modular Mount

PopSocket Modular mount.
So i was looking for some Popsocket mounts but dint find any i liked so i designed one my self.
This is design for my phone and car so if it don't fit just tell me and i will make it more universal.


Phone stand you will need:
1x PopSocket Stand Base.
1x PopSocket Stand Pole 30/40 deg.
1x PopSocket Mount.
1x M3x20mm slotted screw.
1x M3 nut.
1x 4,2x32mm slotted wood screw.

If you need a longer/shorter PopSocket Stand pole just download the STEP-file and edit the length your self.


Car mount you will need:
1x PopSocket car mount.
1x PopSocket mount or PopSocket Mount + Support if you are going to use PopSocket Mount arm Support.
1x M3x20mm slotted screw.
1x M3 nut.
Optinal:
1x PopSocket Mount Arm Support.
1x PopSocket Swivel ball Mount Thread.
1x Popsocket Swivel ball Mount nut.
1x PopSocket Swivel Ball Mount Ball.
2x 1,5x15mm steel wire
1x M3x20mm slotted screw.
1x M3 nut.
If you need a longer/shorter PopSocket Mount Arm Support just download the STEP-file and edit the length your self.
You may need to glue some parts together so they don't turn.


Print settings and orientations:
I have used PLA and works fine for me, where i live we dont get it to hot in the summer. but i recommend to use Petg or something better so that the parts don't deforme.

PopSocket Mount is printed flat with Support everywhere and with Brim, print solid, use the lowest Resolution for best fitment.
PopSocket Mount + Support is printed flat with Support everywhere and with Brim, print solid, use the lowest Resolution for best fitment.
PopSocket Mount Arm Support Printed solid.
PopSocket Stand Base printed flat with 25
