Multipurpose (milling) CNC machine

A multipurpose machine with a movable traverse for the manufacture of large-sized parts. Table 6x2 m, travel distance X 6.2, Y 2.4, Z 0.4, W 1 m. Spindle HSK-A100, 22 kw.This is a part of my bachelor's thesis work. There are drawings in PDF file:Sheet 1 - Drawing of the part and the technological process of its manufacture.Sheet 2 - Typical parts and analysis of solutions in the market of machine tools for processing large-sized workpieces.Sheet 3 - General view of the designed machine.Sheet 4 - Functional-kinematic diagram.Sheet 5 - Hydraulic and Pneumatic Diagrams.Sheet 6 - Drawing of the motor - spindle.Sheet 7 - Drawing of the X-axis feed drive.Motors and electronics: Fanuc, Pneumatic system: Festo, Hydraulic system: Bosch RexrothList of used models:Fanuc motor [Fanuc Beta iSc 8/3000]Roller pinion [https://www.nexengroup.com/nxn/products/details/id/966809]Gearhead [https://www.nexengroup.com/nxn/products/details/id/969100]Gearhead plate [https://www.nexengroup.com/nxn/products/details/id/960875]Rail guides [https://iko.partcommunity.com/3d-cad-models/?languageIso=en&info=iko/linear_way_series/linear_way_h_series]Mill cutter [HSK 100 Feed mill Cutter]Bearings [https://www.skf.com/ru], e.g. NN 3022 TN9/SP [https://www.skf.com/ru/products/super-precision-bearings/cylindrical-roller-bearings/productid-NN%203022%20TN9%2FSP]Tool Griper [HSK F63 Tool Griper ]Table [https://www.haascnc.com/machines/vertical-mills/vf-series/models/large/vf-11-50.html]Coolant tank & Chip Conveyor [https://www.haascnc.com/machines/vertical-mills/universal-machine/models/umc-500.html]Vise [https://www.homge.com.tw/multi-power-cnc-super-vise-hpaq-160]Fixing bolts - standard Autodesk Inventor Library
