Reverse BMG mount
This is a modified BMG mount for this hotend direct drive setup by "hangtight" https://www.thingiverse.com/thing:3466809It mounts with the screws coming in from behind the mountplateI made this in tinkercad by mirroring the original mount, Slicing off the mount screws and extruding a new new section in order to make a spacer 17mm from the old face. Needs 2 m3 bolts that are inserted into the bottom. I suggest using longer M3 hardware like m3x15-m3x25 to increase stiffness of the mount.hangtight feel free to include this in your setup or redesign as needed.
Direct link to the original creator's page
