Locking nut for cheap metal detector shaft

prusaprinters

<p>18 mm/22 mm diameter aluminium shaft, the thread pitch is 1 mm</p> <h3>Print instructions</h3><p>It is similar to the part E in the following diagram:<br/> <a href="https://www.barskasupport.com/spare-part-order/lock-nut-assembly">https://www.barskasupport.com/spare-part-order/lock-nut-assembly</a></p> <p>You could complement it with <a href="https://www.thingiverse.com/thing:3541435">https://www.thingiverse.com/thing:3541435</a></p> <p>It is originally for <a href="https://www.jula.no/catalog/fritid/fritidsaktiviteter/metalldetektorer-og-kompasser/metalldetektorer/metalldetektor-150058/">https://www.jula.no/catalog/fritid/fritidsaktiviteter/metalldetektorer-og-kompasser/metalldetektorer/metalldetektor-150058/</a> Marquant Metal Detector but it seems similar to the Barska Master edition metal detector.</p> <h3> Print Settings</h3> <p><strong>Rafts:</strong> Doesn't Matter</p> <p><strong>Supports:</strong> No</p> <p><strong>Resolution:</strong> 0.2 to 0.1 variable (for the threads is best)</p> <p><strong>Infill:</strong> 50%</p> <p><strong>Notes:</strong></p> <p>Rotate the shape and print with the threads pointing up. No supports required. No cleanup</p>
