Hypercube XY gantry Cable chains
I purchased this cable chain on aliexpress:
https://www.aliexpress.com/item/L1000mm-10-x-10mm-Cable-Drag-Chain-Wire-Carrier-Nylon-Black-Chain-for-CNC-Router-Machine/32762802131.html
and I needed to connect it somehow in my hypercube evolution. I have thought of this system that I consider to be valid enough, some pieces of the original hypercube evolution should be reprinted (like the X carriage) but some parts like the right Y carriage and its clamp can be modified with a drill bit to accommodate the m3 brass inserts , or they can be reprinted.
The bridge you see in the right Y carriage is used to pass the wires between the 2 cable chains and the wires will be held in place by plastic straps.
