Customizable Filament Rod

prusaprinters

<p>This is a height-customizable spool rod that is compatible with the Flashforge Dreamer's standard spool holder. It is also compatible with @BaronWilliam's <a href="https://www.thingiverse.com/thing:704631">Top Mount</a> and <a href="https://www.thingiverse.com/thing:652415"> Internal Side Mount</a> Omnistands.</p> <p>I designed this to be used with my <a href="https://www.thingiverse.com/thing:2104427">Universal Spool Hub</a>.</p> <p>If you are using this rod inside the Dreamer, the max height (aka length) of the rod should be 90 mm. If you are using this outside the printer, then I would suggest a max of 125 mm. The axle diameter is 19 mm.</p> <h3> Print Settings</h3> <p><strong>Printer Brand:</strong></p> <p>FlashForge</p> <p><p class="detail-setting printer"><strong>Printer: </strong> <div><p>FlashForge Creator Pro</p></div><strong>Rafts:</strong></p> <p>No</p> <p><p class="detail-setting supports"><strong>Supports: </strong> <div><p>Yes</p></div><strong>Resolution:</strong></p> <p>0.2</p> <p><p class="detail-setting infill"><strong>Infill: </strong> <div><p>75%</p></div></p> <p><strong>Notes:</strong></p> <p>Since this rod is intended to hold 1 kg spools, you want a high infill percentage. I printed with 75%.</p> <p>Although you could print this vertically, I recommend printing it lying down on its side (lengthwise going left &lt;-&gt; right). This would allow for best strength. A vertical print would more easily snap in half due to layer separation risk. If you print it lying down on its side, you will need to use supports.</p> </p></p></p> Category: 3D Printer Accessories
