Alphacool Eisbaer Solo Mount and Heat Exchanger for Water Cooled Hotends
prusaprinters
<p>This is the water cooling setup I use in my CorEssentials BETA for the E3D Chimera Aqua. Obviously this will fit most other printers. You can find out more about the machine on GITHUB:</p> <p><a href="https://github.com/MacNite/CorEssentials">https://github.com/MacNite/CorEssentials</a></p> <p>To built this exact setup you will need:</p> <p>Alphacool Eisbaer Solo<br/> some M3 screws<br/> 60x25mm fan<br/> G1/4 mounts for your choosen tube diameter (for E3D that would be G1/4 to 4mm OD Tube)</p> <p><a href="https://www.ebay.de/itm/Pneumatik-IQS-Standard-gerade-Steckverschraubung-zylindrisch-MSV-alle-Gr%C3%B6%C3%9Fen/222673814779?ssPageName=STRK%3AMEBIDX%3AIT&var=521526744321&_trksid=p2057872.m2749.l2649">https://www.ebay.de/itm/Pneumatik-IQS-Standard-gerade-Steckverschraubung-zylindrisch-MSV-alle-Gr%C3%B6%C3%9Fen/222673814779?ssPageName=STRK%3AMEBIDX%3AIT&var=521526744321&\_trksid=p2057872.m2749.l2649</a></p> <p>LED heatsink like this, needs to be cut to size</p> <p><a href="https://www.ebay.de/itm/150x60x25mm-K%C3%BChler-Aluminiumk%C3%BChlk%C3%B6rper-Extrudierter-K%C3%BChlk%C3%B6rper-f%C3%BCr-LED-RI-YTM-Ld/114003337531?ssPageName=STRK%3AMEBIDX%3AIT&_trksid=p2057872.m2749.l2649">https://www.ebay.de/itm/150x60x25mm-K%C3%BChler-Aluminiumk%C3%BChlk%C3%B6rper-Extrudierter-K%C3%BChlk%C3%B6rper-f%C3%BCr-LED-RI-YTM-Ld/114003337531?ssPageName=STRK%3AMEBIDX%3AIT&\_trksid=p2057872.m2749.l2649</a></p> <p>The general concept of this cooler / heat exchanger is really simple:<br/> ALPHACOOL Eisbaer is an all in one solution as a Reservoir, Heat-Exchanger / Heatsink and Pump. The LED heatsink and fan are just there to increase the performance. I have also used the ALPHACOOL Eisbaer only mounted to a metal plate of other 3D printers. But obviously this becomes quite in-effective if you use a closed chamber and everything may heat up.</p> <p>As an additional inspiration you may have a look at the Sparkcube EDGE by Sparklab:<br/> <a href="https://the-sparklab.de/sparkcube-edge-255x175x400/">https://the-sparklab.de/sparkcube-edge-255x175x400/</a></p> <p>If there are any questions / uncertainties feel free to ask them in the comments.</p> <h3>Print instructions</h3><p>Category: 3D Printer Parts</p>
