picatinny dovetail 3d models

This is a precise Picatinny dovetail engineered specifically for telescope red dot sights, featuring meticulously placed holes that accommodate 8-32 inserts. ...It's been carefully designed to fit snugly onto the Vixen clamp (thing number 2854473),...

Whether you're an airsoft enthusiast or a real steel owner, Picatinny rail optics can be pricey, often exceeding $120.\r\n\r\nWith this adapter, you can integrate dovetail scopes, red dots, lasers, or any accessory that attaches to a standard 12mm...

Just needed this about a third longer for the scope my little brother bought for his airsoft gun. ...Works great with the 3/8 inch dovetail scope.

Picatinny Rail and 3/8 Dovetail Combo Version Includes Backup Sighting Tube. Also Available, Crosshair Sight: https://www.thingiverse.com/thing:2782564 Updated 12/9/2019: Errors in Both Models Corrected Where the Bottom Rail Lug Was Slightly Offset...

Inspired by Riccardo Langier, completely rebuilt to accommodate an M3 bolt and nut rather than a 3D printed pin.

I designed this Picatinny to Dovetail rail adapter, which also adds about an inch, to an inch and a half to the height of the sight. Also, I recommend setting the scaling to 1.01 instead of just 1, otherwise, you might need to sand it a bit. ...Enjoy!

Main components come in three different configurations: dovetail, Picatinny (also known as Weaver), and flat surface attachment. ...Connect side rails to the primary section using M3 screws.

... Dimensions:- Overall size: 8cm (L) x 6.4cm (h) x 2.8cm (w)- Picatinny length: 8cm- Dovetail length: 7cm- Barrel mount diameter: 2.3 cm Print as oriented in the file. Supports will be needed. ...Recommend using ABS in 100% infill for durability

... on. But telescope accessories often use a dovetail mount, while rifle accessories use a Picatinny Rail mount (or the metric version, called the NATO Accessory Rail). ...This adapter simply lets you mount a rifle laser onto an astronomy telescope.

This adapter mounts a picatinny scope onto a pellet gun by converting a dovetail rail to a picatinny rail, enabling precise aim with the added stability of a high-quality optic.

This dovetail-to-picatinny mount was specifically designed for my Henry H100T rifle, and I've managed to get it as low-profile as possible. The Vortex Crossfire red dot sight is a primary focus of this project. A tight fit on the dovetail...

This is a 3D printable Dovetail to Picatinny rail adapter. ...Printed vertically with ABS.

This Adapter converts the standard picatinny rail to a Dovetail 11mm Mount. The adapter adds about 1 centimeter of space between the picatinny rail and the sight itself. I am using 3 M3x30mm Bolts to keep everyting in place, although 1 bolt...

Model Maker Crafted a Precision 30MOA Dovetail to Picatinny Base Mount with Exceptional Durability and Performance, Integrating seamlessly with SketchUp 2018. The Dovetail to Picatinny Long Rail Attachment is designed for Optimal Accuracy and Smooth...

This is a replacement picatinny rail for the original dovetail rail provided with the PP750 airgun. You can use the original screws to mount the rear picatinny rail. The front rail is a slide over picatinny rail. ... No supports, 100% infill, 0,2...

11mm / 3/8th inch dovetail rail to picatinny rail adaptor. I like the options available on Thingiverse for rail adapters, but most of them raise the scope too much. This design gives me the ability to mount picatinny optics easily without raising...

An adapter that I originally made for my beeman qb chief pellet gun so I could attach a rifle scope to it that required a picatinny rail. I was too excited for the metal adapter I ordered to come in so I designed and printed this in the meantime. I...

11mm / 3/8th inch dovetail rail to picatinny rail adaptor. I like the options available on Thingiverse for rail adapters, but most of them raise the scope too much. This design gives me the ability to mount picatinny optics easily without raising the...

I bought this [super cheap red dot sight](https://tinyurl.com/vda9u2ss) for my airsoft gun but, i didn't notice it wasn't Picatinny until it got here, i was going to return it but then I remembered I have a 3d printer ^_^ I didn't see any adapters...

an adapter for mounting picatinny accesoires to a Hi-Capa airsoft pistol. i took my measurements from a KLI/SRC brand model, don't know how well it will fit other brands, but from what i've heard hi-capas in general tend to be pretty similar. ...enjoy!

<p>Secure it with three 4-5mm grub screws.</p><p>The CAD files are included.&nbsp;</p>

A 11mm dovetail adapter converts to the standard Weaver/Picatinny rail system, allowing for versatile mounting options on various devices.

This will let you mount a picatinny or weaver mount scope or sighting accessory to a vixen type female dovetail on a telescope or tripod.

I couldn't find a low-profile Picatinny weaver to 12mm dovetail adapter for my pellet gun, so I designed one that's as compact and easy to print as possible. If you want one customized, message me - I don't mind modifying it for you. ...This design uses...

I couldn't find a low-profile Picatinny weaver to 12mm dovetail adapter for my pellet gun, so I designed one that's as low profile and simple to print as possible. If you want one customized, message me - I don't mind modifying it for you. ...This...

This creation allows to mount a red dot on common airguns with dovetail rail. I used two M3 nuts and two M3x40 screws and shortened them to 35 mm (it's not necessary, just for aesthetics). I recommend using 60% infill (honeycomb) or more to avoid...

This creation was crafted using the powerful tools of Tinkercad. ...Make any necessary changes directly on their website at https://www.tinkercad.com/things/2HKm8ClMIci.

Fixed the original designers work. Screw hole was messed up in CAD. Removed the weird little wedge overhang. ...Not needed for my case.

Parametric Red Dot Sight Adapter - Astro Dovetail to NATO Rail Provides NATO/Picatinny/Weaver-compatible rail for mounting a standard red dot sight (reflex sight) or a standard target scope to the telescope. Includes OpenSCAD source file in case...

Red Dot Sight Adapter - Astro Dovetail to NATO Rail Mount this adapter to your Astro dovetail shoe with its 34 mm base for secure attachment. Designed for dovetail shoes featuring a 32.5 mm base width and a 60 degree flank angle, this adapter...
